Available in Thicknesses of 0.5 mm, 1 mm, 1.5 mm & 2 mm.
Specifications:
- Length: 300 mm,
- Width: 200 mm,
- Thickness: 1 mm & 0.5 mm.
Description
Detailed Specifications:
<ul>
<li>Length: 200 mm,</li>
<li>Width: 300 mm,</li>
<li>Thickness: 1 mm,</li>
<li>Approximate Hole Number (PPI): 110,</li>
<li>Range of Hole Numbers (PPI): 100-120,</li>
<li>Density (g/m2): ≥ 250,</li>
<li>Color of Foam: Silver gray,</li>
<li>Tensile strength (N/20mm): Longitudinal ≥ 30, Transversal ≥ 20,</li>
<li>Elongation (％): Longitudinal ≥ 5, Transversal ≥ 12,</li>
<li>Resistance(mΩ/100mm*10mm): Longitudinal ≤ 65, Transversal ≤ 85,</li>
<li>Composition(wt%): Cu- ≤ 0.010, C- ≤ 0.050, Si- ≤ 0.005, Fe- ≤ 0.030, S- ≤ 0.008, Ni＋Co – 99.9.</li>
</ul>
